Please see multi protocol 8000 modules for additional information on protocols that can be added to this card.
Ordering Information:
| Part Number |
Description |
| EXC-Unet2/xx |
Multi-protocol interface for USB or Ethernet equipped computers |
Note:
"xx” specifies the modules ordered with the carrier board (up to 4 modules).
"-001" added to the end of the part number specifies conformal coating option.
Available Modules for the EXC-Unet2
ARINC-429 Modules
A0 - 5 Channels ARINC 429 module, Software selectable for Receive or Transmit
ARINC-708 Modules
C0 - 2 Channels ARINC 708/453 module, SW selectable as Tx or Rx
ARINC-708 Modules
D0 - 1 Channel H009 module (double size)
MIL-STD-1553 multi-function Modules
|
F1- Transformer coupled mode
|
|
F2- Direct coupled mode
|
MIL-STD-1760 single function Modules
|
H1- 1760 Transformer coupled mode
|
|
H2- 1760 Direct coupled mode
|
Discrete Modules
I0- 10 Ch Discrete, SW selectable for In/Out and TTL/Avionics 0-32 Volt thresholds
Serial Modules
|
J1- Ch0 RS232, Ch1 RS232
|
J4- Ch0 RS485, Ch1 RS485
|
|
J2- Ch0 RS232, CH1 RS485
|
J5- Ch0 RS485, CH1 RS422
|
|
J3- Ch0 RS232, CH1 RS422
|
J6- Ch0 RS422, CH1 RS422
|
MIL-STD-1760 multi-function Modules
|
L1- 1760 Transformer coupled mode
|
|
L2- 1760 Direct coupled mode
|
MIL-STD-1760 monitor only Modules
|
M1- PxM-1760 Transformer coupled mode
|
|
M2- PxM-1760 Direct coupled mode
|
ARINC-717 1Rx & 1Tx channels Modules
|
N1- HBP signals
|
|
N2- BPRZ signals
|
Analog to Digital & Digital to Analog Modules
|
P1- DAC outputs only (10 Single Ended or 5 Differential)
|
|
P2- ADC inputs only (5 Single Ended or 5 Differential)
|
|
P3 = Combined DAC and ADC
(4 Single Ended or 2 Differential DAC outputs and 3 Single Ended or 3 Differential ADC inputs)
|
MMSI Modules
|
R5- 5 ports EBR-1553 hub +1 cBM port (10 Mbps 1553 protocol, RS-485 front-end)
|
ARINC-825 (Canbus) Modules
MIL-STD-1553 single function Modules
|
T1- Transformer coupled mode
|
|
T2- Direct coupled mode
|
MIL-STD-1553 monitor only Modules
|
V1- Transformer coupled mode
|
|
V2- Direct coupled mode
|
