The EXC-8000PCIe104/xx card for the PC/104-Express system supports up to twenty ARINC-429 channels in any combination of transmit and/or receive. All of the channels feature error injection and detection.
The receive channels allow for the storage of all selected labels with status and time tag information appended to each word, and also allow for filtering and multi-storage modes of data words.

The transmit channels operate via a transmit ‘instruction stack’ which allows scheduling of data transmissions and reduces the need for host computer intervention.

The EXC-8000PCIe104/xx card is supplied with C drivers, including source code, Mystic application program and  may be used with Exalt, Excalibur’s Analysis and Laboratory Tools, a Windows monitoring application. Mating connector provided for I/O connection.

Please see multi protocol 8000 modules for additional information on protocols that can be added to this card.

Please see our Dragon rugged PC/104 system for a complete PC/104 solution.

Ordering Information:

Part Number  Description
EXC-8000PCIe104/xx   Multi-protocol interface for PC/104-Express compatible systems.
M8K429RTx  ARINC-429 interface module with 5 programmable channels.


"xx” specifies the modules ordered with the carrier board.
"-E" added to the end of the part number specifies extended temperature (-40° to +85°C) option.
"-R" rugged configuration

"-001" added to the end of the part number specifies conformal coating option.
