EXC-4000cPCI/xx card & M4K825CAN module

Excalibur Systems

The EXC-4000cPCI/xx card for the Compact PCI bus, supporting 32-bit modules, supports up to forty ARINC-825 CAN Bus channels using the M4K825CAN module. In receive mode, the module stores all or selected messages with status and Time Tag information appended to each message. In transmit mode, the module operates via a transmit Bandwidth Frame which allows scheduling of data transmissions and reduces the need for host computer intervention.

The EXC-4000cPCI/xx is supplied with C drivers, including source code. Mating connector provided for I/O connections.

Please see multi protocol 4000 modules for additional information on protocols that can be added to this card.

Ordering Information:

Part Number Description
EXC-4000cPCI/xx Multi-protocol interface for Compact PCI compatible systems. [4 modules]

SAx   M4K825CAN2 2 independent channels of ARINC-825 CAN bus channels
SBx   M4K825CAN4 Same as above with 4 independent channels
SCx   M4K825CAN6 Same as above with 6 independent channels
SDx   M4K825CAN10 Same as above with 10 independent channels
X4K-xx 50cm cable adapter for EXC-4000 card [optional]


Note:
"xx” specifies the modules ordered with the carrier board.
"-E" added to the end of the part number specifies extended temperature (-40° to +85°C) option.
"-001" added to the end of the part number specifies conformal coating option.
